Description
Description
Portable Single Gas Detector features a user-friendly all-English operation interface. It is a high-cost-performance waterproof single gas detector meticulously designed for you by our company. This device employs internationally renowned sensors, boasting high sensitivity, stability, and reliability. The waterproof single gas detector is widely applicable in various settings where the concentration of toxic and harmful gases needs to be detected, including oil extraction, smelting, chemical industry, municipal services, sewage treatment, power generation, gas, mining, tunnel construction, firefighting, warehousing, papermaking, pharmaceuticals, brewing, and many others
Technical Parameters
|
Test gas |
Combustible and toxic gases |
| Detection mode | Natural diffusion |
| Detection principle | Semiconductor/catalysis/electrochemistry |
| scope of test | See Schedule |
| Display | LCD digital display of gas type /gas concentration/ status |
|
Response time |
T90<10s |
|
Indication mode |
LCD display real-time concentration |
|
Alarm indication |
Light emitting diode, sound, vibration |
|
Working environment temperature |
-10℃～55℃，Humidity<93%RH no condensation |
|
Power |
3.7V 1700mA rechargeable lithium battery |
|
Grade of protection |
IP65 |
|
Weight |
Around 132g (including battery and accessories) |
|
Size |
100mm*58mm*30mm |
| Explosion-proof mark |
Ex ia IIC T4 Ga; |
|
Explosion proof No |
CLEx24.1020 |
